Universal controller VRP-M


00132070_0

UNIVERSAL, STATIC

For contaminated extract air or for pressure control

Modular control components for VAV terminal units, especially for aggressive media in extract air systems

  • Module selection based on application
  • Actuators with selected actuator forces

Options

  • Actuators with safety function for 'damper blade OPEN' and 'damper blade CLOSED' (spring return actuators)

Application

Application

  • Electronic volume flow controllers of Type Universal (static) are designed for use with VAV terminal units.
  • Volume flow control or differential pressure control based on static differential pressure measurement
  • Dynamic differential pressure transducer and electronic controller can be fitted together in one casing or in separate casings
  • Actuator or spring return actuator is separate
  • The output signals of the room temperature controller, central BMS, air quality controller or similar units control the volume flow rate setpoint
  • Override control by means of switches or relays
  • Volume flow rate actual value or differential pressure actual value is available as linear voltage signal
  • Controller parameters are factory set
  • On-site adjusting is not required
  • Please note that in critical cases, material compatibility testing must be carried out on the air terminal unit and the differential pressure transducer, taking into consideration the harmful substances involved and the concentrations in which they occur.

Description

Parts and characteristics

  • Sensor for static differential pressure measurements
  • Separate actuator
  • Mechanical stops for limiting the damper blade positions
  • Actuators with overload protection
  • Release button to allow for manual operation

Maintenance

  • Zero point correction of the static differential pressure transducer should be carried out once per year (recommendation)

Technical information

Volume flow control, Produktbeziehungen

  • Volume flow control

Functional description

VAV terminal units control the volume flow in a closed loop, i.e. measurement – comparison – control.

The volume flow rate is determined by measuring the differential pressure (effective pressure). For this purpose the VAV terminal unit is fitted with a differential pressure sensor.

The static differential pressure transducer transforms the effective pressure into a voltage signal. The volume flow rate actual value is hence available as a voltage signal. The factory setting is such that 10 V DC always corresponds to the nominal volume flow rate (Vnom).

The volume flow rate setpoint value comes from a higher-level controller (e.g. room temperature controller, air quality controller, central BMS) or from switch contacts. Variable volume flow control results in a value between Vmin and Vmax. It is possible to override the room temperature control, e.g. by a complete shut-off of the duct.

The controller compares the volume flow rate setpoint value to the actual value and controls the actuator accordingly if there is a difference.

The volume flow rate parameters Vmin and Vmax are set on potentiometers (VRP) or stored in the controller. Voltage ranges are factory stored in the controller. Changes on the customer's site can easily be carried out using a potentiometer, an adjustment device or a notebook with service tool.

Volume flow control

  • The volume flow controller works independent of the duct pressure
  • Differential pressure fluctuations do not result in permanent volume flow rate changes
  • To prevent the control from becoming unstable, a dead band is allowed within which the damper blade does not move.
  • The factory set volume flow rate parameters can be altered by the customer

Variants, Product details

  • Variants
  • MP bus/Analogue
  • Analogue 2 – 10 V DC
  • Analogue (Gruner)

Any attachments are to be defined with the order code of the VAV terminal unit.

Universal controller, static, for VAV terminal units, volume flow control

Order code detail Controller Static differential pressure transducer Actuator VAV terminal units
Order code detail Part number Type Part number Type Part number Type

BP3

M466EN6

VRP-M

M546EJ1

VFP-300

M466EQ9

NM24A-V-ST

① ② ③ ⑤ ⑥ ⑦ ⑧

BP1

M466EN6

VRP-M

M546EJ1

VFP-300

M466ER0

SM24A-V-ST

BPB

M466EN6

VRP-M

M546EJ1

VFP-300

M466DR2

NF24A-V-ST spring return actuator

① ② ③ ④ ⑤ ⑥ ⑦

BPG

M466EN6

VRP-M

M546EJ1

VFP-300

M466EQ2

LMQ24A-SRV-ST fast-running actuator

① ⑥ ⑧

BPG

M466EN6

VRP-M

M546EJ1

VFP-300

M466EQ3

NMQ24A-SRV-ST fast-running actuator

② ③ ④ ⑤ ⑦

BB3

M546EG2

VRP

M546EJ1

VFP-300

M466DJ8

NM24A-V

① ② ③ ⑤ ⑥ ⑦ ⑧

BB1

M546EG2

VRP

M546EJ1

VFP-300

M466DG8

SM24A-V

BBB

M546EG2

VRP

M546EJ1

VFP-300

M466DR1

NF24A-V spring return actuator

① ② ③ ④ ⑤ ⑥ ⑦

XD1

M546ED5

GUAC-S3

Included with GUAC-S3

M466EL7

227-024-08-V

① ② ③ ④ ⑤ ⑥ ⑦

XD3

M546ED5

GUAC-S3

Included with GUAC-S3

A00000051738

361C-024-20-V/ST07 spring return actuator

① ② ③ ④ ⑤ ⑥ ⑦

① TVR, TVZ, TVA up to nominal size 250

② TVR, TVZ, TVA from nominal size 315

③ TVJ

④ TVT

⑤ TZ-Silenzio, TA-Silenzio

⑥ TVRK up to nominal size 250

⑦ TVRK from nominal size 315

⑧ TVLK


Universal controller, static, for VAV terminal units, differential pressure control

Order code detail Controller Static differential pressure transducer Actuator VAV terminal units
Order code detail Part number Type Part number Type Part number Type

BR3

M466EN6

VRP-M

M546EJ6

VFP-100

M466EQ9

NM24A-V-ST

① ② ③ ⑤ ⑥ ⑦ ⑧ ⑨

BR1

M466EN6

VRP-M

M546EJ6

VFP-100

M466ER0

SM24A-V-ST

BRB

M466EN6

VRP-M

M546EJ6

VFP-100

M466DR2

NF24A-V-ST spring return actuator

① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨

BRG

M466EN6

VRP-M

M546EJ6

VFP-100

M466EQ2

LMQ24A-SRV-ST fast-running actuator

① ⑥ ⑧

BRG

M466EN6

VRP-M

M546EJ6

VFP-100

M466EQ3

NMQ24A-SRV-ST fast-running actuator

② ⑤ ⑦ ⑨

BS3

M466EN6

VRP-M

M546EJ7

VFP-600

M466EQ9

NM24A-V-ST

① ② ③ ⑧ ⑨

BS1

M466EN6

VRP-M

M546EJ7

VFP-600

M466ER0

SM24A-V-ST

BSB

M466EN6

VRP-M

M546EJ7

VFP-600

M466DR2

NF24A-V-ST spring return actuator

① ② ③ ④ ⑧ ⑨

BSG

M466EN6

VRP-M

M546EJ7

VFP-600

M466EQ2

LMQ24A-SRV-ST fast-running actuator

① ⑧

BSG

M466EN6

VRP-M

M546EJ7

VFP-600

M466EQ3

NMQ24A-SRV-ST fast-running actuator

② ③ ④ ⑨

BG3

M546ED1

VRP-STP

M546EJ6

VFP-100

M466DJ8

NM24A-V

① ② ③ ⑤ ⑥ ⑦ ⑧ ⑨

BG1

M546ED1

VRP-STP

M546EJ6

VFP-100

M466DG8

SM24A-V

BGB

M546ED1

VRP-STP

M546EJ6

VFP-100

M466DR1

NF24A-V spring return actuator

① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨

BH3

M546ED1

VRP-STP

M546EJ7

VFP-600

M466DJ8

NM24A-V

① ② ③ ⑧ ⑨

BH1

M546ED1

VRP-STP

M546EJ7

VFP-600

M466DG8

SM24A-V

BHB

M546ED1

VRP-STP

M546EJ7

VFP-600

M466DR1

NF24A-V spring return actuator

① ② ③ ④ ⑧ ⑨

XE1

M546ED6

GUAC-P1

Included with GUAC-P1

M466EL7

227-024-08-V

① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨

XE3

M546ED6

GUAC-P1

Included with GUAC-P1

A00000051738

361C-024-20-V/ST07 spring return actuator

① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨

XF1

M546ED7

GUAC-P6

Included with GUAC-P6

M466EL7

227-024-08-V

① ② ③ ④ ⑧ ⑨

XF3

M546ED7

GUAC-P6

Included with GUAC-P6

A00000051738

361C-024-20-V/ST07 spring return actuator

① ② ③ ④ ⑧ ⑨

① TVR up to nominal size 250

② TVR from nominal size 315

③ TVJ

④ TVT

⑤ TZ-Silenzio, TA-Silenzio

⑥ TVZ, TVA up to nominal size 250

⑦ TVZ, TVA from nominal size 315

⑧ TVRK up to nominal size 250

⑨ TVRK from nominal size 315


Any attachments must be defined with the order code of the VAV terminal unit.


Application

  • Electronic volume flow controller VRP-M, combined with a static differential pressure transducer VFP-300, as Universal controller
  • Variable air or constant air volume flow control
  • The flow rate is measured using the static measurement principle
  • Voltage range for the actual and setpoint value signals 0 – 10 V DC or 2 – 10 V DC
  • Separate inputs for override controls enable the centralised switching of groups of controllers
  • With MP bus interface: Up to eight users, such as VRP-M, can be addressed on an MP bus (LAN). This allows for the integration with higher-level systems. DDC controller with MP bus interface to control the Universal controller. Belimo interface UK24LON for LonWorks systems; UK24EIB for EIB systems; UK24MOD for Modbus systems; UK24BAC for BACnet
  • When the MP bus interface is used, the analog 0 – 10 V or 2 – 10 V interface cannot be used at the same time.
  • The MP bus interface cannot be used with fast-running actuators

Construction

Volume flow controller VRP-M with static differential pressure transducer VFP-300

  • BP3: Actuator NM24A-V-ST for TVR, TVJ, TZ-Silenzio, TA-Silenzio TVZ, TVA, TVLK
  • BP1: Actuator SM24A-V-ST for TVT
  • BPB: Spring return actuator NF24A-V-ST for TVR, TVJ, TVT, TZ-Silenzio, TA-Silenzio TVZ, TVA, TVRK
  • BPG: Fast-running actuator LMQ24A-SRV-ST for TVR, TVZ, TVA, TVRK up to nominal size 250, and TVLK or NMQ24A-SRV-ST for TVR, TVZ, TVA, TVRK from nominal size 315 and TVJ, TVT, TZ-Silenzio, TA-Silenzio

Signal voltage ranges

  • 0: 0 – 10 V DC
  • 2: 2 – 10 V DC with shut-off function (< 0.1 V DC)

Operating modes

E: Single and M: Master

  • Vmin: Minimum volume flow rate
  • Vmax: Maximum volume flow rate


S: Slave operation

  • Vmin: 0 %
  • Vmax: Volume flow rate ratio to the master controller


F: Constant value

  • Vmin: constant volume flow rate
  • Vmax: 100 %


Parameters are factory set. The customer defines the required operating mode and the volume flow rates in the order code at the time of ordering.

Commissioning

  • On-site adjusting is not required
  • When installing the VAV terminal units it is important to assign each room the correct unit based on the ordered volume flow rates
  • After successful installation and wiring the controller is ready for use
  • Carry out zero point correction for the controller and adapt the actuator.
  • The volume flow rate parameters Vmin and Vmax can be adjusted at a later stage using an adjustment device

Volume flow and differential pressure controller VRP-M

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Supply voltage (DC)

24 V DC ± 10 %

Power rating (AC)

including differential pressure transducer, without actuator max. 2.6 VA

Power rating (DC)

including differential pressure transducer, without actuator max. 1.1 VA

Setpoint value signal input

0 – 10 V DC, Ra > 200 kΩ

Actual value signal output

0 – 10 V DC, 0.5 mA max.

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Static differential pressure transducer VFP-300

Supply voltage

from the controller

Measuring range

0 – 300 Pa

Linearity

± 3 Pa

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Actuators NM24A-V and NM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

3.5 W max.

Torque

10 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.710 kg


Actuators SM24A-V and SM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

4 W max.

Torque

20 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.910 kg


Spring return actuators NF24A-V and NF24A-V-ST

Supply voltage

from the controller

Power rating (AC)

9 VA max.

Power rating (DC)

6.5 W max.

Torque

10 Nm

Running time for 90°

200 – 300 s

Spring return time

< 20 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

1.91 kg


Fast-running actuator LMQ24A-SRV-ST

Supply voltage

from controller VRP-M

Power rating (AC)

23 VA max.

Power rating (DC)

13 W max.

Torque

4 Nm

Running time for 90°

2.5 s

Control signal

from controller VRP-M

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.810 kg


Fast-running actuator NMQ24A-SRV-ST

Supply voltage

from controller VRP-M

Power rating (AC)

23 VA max.

Power rating (DC)

13 W max.

Torque

8 Nm

Running time for 90°

4 s

Control signal

from controller VRP-M

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.970 kg


Application

  • Electronic volume flow controller VRP, combined with a static differential pressure transducer VFP-300, as Universal controller
  • Variable air or constant air volume flow control
  • The flow rate is measured using the static measurement principle
  • Voltage range for the actual and setpoint value signals 2 – 10 V DC
  • Separate inputs for override controls enable the centralised switching of groups of controllers

Construction

Volume flow controller VRP with static differential pressure transducer VFP-300

  • BB3: Actuator NM24A-V-ST for TVR, TVJ, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK, TVLK
  • BB1: Actuator SM24A-V-ST for TVT
  • BBB: Spring return actuator NF24A-V-ST for TVR, TVJ, TVT, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK

Signal voltage range

  • 2: 2 – 10 V DC

Operating modes

E2: Single and M2: Master

  • Vmin: Minimum volume flow rate
  • Vmax: Maximum volume flow rate


S2: Slave operation

  • Vmin: 0 %
  • Vmax: Volume flow rate ratio to the master controller


F2: Constant value

  • Vmin: constant volume flow rate
  • Vmax: 100 %


Parameters are factory set. The customer defines the required operating mode and the volume flow rates in the order code at the time of ordering.

Commissioning

  • On-site adjusting is not required
  • When installing the VAV terminal units it is important to assign each room the correct unit based on the ordered volume flow rates
  • After successful installation and wiring the controller is ready for use
  • Carry out zero point correction for the controller and adapt the actuator.
  • The volume flow rate parameters Vmin and Vmax can be adjusted at a later stage using potentiometers

Volume flow controller VRP

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Power rating (AC)

without actuator max. 2.6 VA

Setpoint value signal input

2 – 10 V DC, Ra >100 kΩ

Actual value signal output

2 – 10 V DC linear, max. 0.5 mA

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Static differential pressure transducer VFP-300

Supply voltage

from the controller

Measuring range

0 – 300 Pa

Linearity

± 3 Pa

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Actuators NM24A-V and NM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

3.5 W max.

Torque

10 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.710 kg


Actuators SM24A-V and SM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

4 W max.

Torque

20 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.910 kg


Spring return actuators NF24A-V and NF24A-V-ST

Supply voltage

from the controller

Power rating (AC)

9 VA max.

Power rating (DC)

6.5 W max.

Torque

10 Nm

Running time for 90°

200 – 300 s

Spring return time

< 20 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

1.91 kg


Application

  • Electronic volume flow controller GUAC-S3 as Universal controller with integral differential pressure transducer
  • Variable air or constant air volume flow control
  • The flow rate is measured using the static measurement principle
  • Voltage range for the actual and setpoint value signals 0 – 10 V DC or 2 – 10 V DC

Construction

Volume flow controller GUAC-S3

  • XD1: Actuator 227-024-08-V for TVR, TVJ, TVT, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK
  • XD3: Spring return actuator 361C-024-20-V/ST07 for TVR, TVJ, TVT, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK

Signal voltage ranges

  • 0: 0 – 10 V DC
  • 2: 2 – 10 V DC with shut-off function (< 0.8 V DC)

Operating modes

E: Single and M: Master

  • Vmin: Minimum volume flow rate
  • Vmax: Maximum volume flow rate


S: Slave operation

  • Vmin: 0 %
  • Vmax: Volume flow rate ratio to the master controller


F: Constant value

  • Vmin: constant volume flow rate
  • Vmax: 100 %


Parameters are factory set. The customer defines the required operating mode and the volume flow rates in the order code at the time of ordering.

Commissioning

  • On-site adjusting is not required
  • When installing the VAV terminal units it is important to assign each room the correct unit based on the ordered volume flow rates
  • After successful installation and wiring the controller is ready for use
  • Carry out zero point correction for the controller using adjustment device AT-VAV-G
  • The volume flow rate parameters Vmin and Vmax can be adjusted at a later stage using an adjustment device

Volume flow controller GUAC-S3

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Supply voltage (DC)

24 V DC ± 20 %

Power rating (AC)

without actuator max. 1.2 VA

Power rating (DC)

without actuator max. 0.6 W

Setpoint value signal input

0 – 10 V DC, Ra > 100 kΩ

Actual value signal output

0 – 10 V DC, 0.5 mA max.

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Actuator 227-024-08-V

Supply voltage

from the controller

Power rating (AC)

3 VA max.

Power rating (DC)

2 W max.

Torque

8 Nm

Running time for 90°

60 – 120 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54 (cable entry at the bottom)

EC conformity

EMC according to 2014/30/EU

Weight

0.530 kg


Spring return actuator 361C-024-20-V

Supply voltage

from the controller

Power rating (AC)

10 VA max.

Power rating (DC)

8 W max.

Torque

20 Nm

Running time for 90°

150 s

Spring return time

< 15 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54 (cable entry at the bottom)

EC conformity

EMC according to 2014/30/EU

Weight

1.8 kg


Pressure control, MP bus/Analogue Δp, Analogue 2 – 10 V DC Δp, Analogue Δp (Gruner)

  • Pressure control
  • MP bus/Analogue Δp
  • Analogue 2 – 10 V DC Δp
  • Analogue Δp (Gruner)

Functional description

The static differental pressure transducer transforms the differential pressure into a voltage signal. The differential pressure actual value is available as a voltage signal. The factory setting is such that 10 V DC always corresponds to the nominal differential pressure (Δpnom).

The differential pressure setpoint value is either a constant value or it comes from a setpoint adjuster or from switch contacts.

The controller compares the differential pressure setpoint value to the actual value and controls the actuator accordingly.

The differential pressure parameters are set on a potentiometer (VRP-STP) or stored in the controller. Voltage ranges are factory stored in the controller. Changes on the customer's site can easily be carried out using a potentiometer, an adjustment device or a notebook with service tool.

Constant pressure control

  • The differential pressure controller works independent of the duct pressure
  • Pressure fluctuations do not result in permanent differential pressure changes
  • To prevent the control from becoming unstable, a dead band is allowed within which the damper blade does not move.
  • The factory set differential pressure parameters can be altered by the customer

Variable pressure control

  • Relays or switch contacts connected to the control signal input Y/Z can be used to achieve constant pressures ∆pmin and ∆pmax or to override various control settings.

Application

  • Electronic differential pressure controller VRP-M, combined with a static differential pressure transducer VFP-100 or VFP-600, as Universal controller
  • Variable or constant differential pressure control
  • The differential pressure is measured using the static measurement principle
  • Voltage range for the actual and setpoint value signals 0 – 10 V DC or 2 – 10 V DC
  • Separate inputs for override controls enable the centralised switching of groups of controllers
  • With MP bus interface: Up to eight VRP-M users can be addressed on an MP bus (LAN); Belimo-Interface UK24LON for LonWorks systems; UK24EIB for EIB systems; UK24MOD for Modbus systems; UK24BAC for BACnet; DDC controllers with MP bus interface can control the Universal controller via data transfer
  • When the MP bus interface is used, the analog 0 – 10 V or 2 – 10 V interface cannot be used at the same time.
  • The MP bus interface cannot be used with fast-running actuators

Construction

Differential pressure controller VRP-M with static differential pressure transducer VFP-100

  • BR3: Actuator NM24A-V-ST for TVR, TVJ, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK
  • BR1: Actuator SM24A-V-ST for TVT
  • BRB: Spring return actuator NF24A-V-ST for TVR, TVJ, TVT, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK
  • BRG: Fast-running actuator LMQ24A-SRV-ST for TVR, TVZ, TVA, TVRK up to nominal size 250, and TVLK or NMQ24A-SRV-ST for TVR, TVZ, TVA, TVRK from nominal size 315


Volume flow controller VRP-M with static differential pressure transducer VFP-600

  • BS3: Actuator NM24A-V-ST for TVR, TVJ, TVRK
  • BS1: Actuator SM24A-V-ST for TVT
  • BSB: Spring return actuator NF24A-V-ST for TVR, TVJ, TVT, TVRK
  • BSG: Fast-running actuator LMQ24A-SRV-ST for TVR, TVRK up to nominal size 250, or NMQ24A-SRV-ST for TVJ, TVT and TVR, TVRK from nominal size 315

Signal voltage ranges

  • 0: 0 – 10 V DC
  • 2: 2 – 10 V DC with shut-off function (< 0.1 V DC)

Operating modes

  • Z: Supply air
  • A: Extract air

Factory settings are as follows: Differential pressure ∆pmin as ordered and for room pressure controllers the adequate ∆pnom. The effective pressure sensor of the VAV terminal unit is short circuited.

Commissioning

  • On-site adjusting is not required
  • When installing the VAV terminal units it is important to assign each room the correct unit based on the ordered differential pressures
  • Tubing of the static differential pressure transducer by others
  • For positive room pressure: Connect room pressure to Plus, reference room to Minus
  • For negative room pressure: Connect room pressure to Minus, reference room to Plus
  • For supply air duct pressure: Connect static pressure of the duct to Plus
  • For extract air duct pressure: Connect static pressure of the duct to Minus
  • After successful installation, tubing and wiring the controller is ready for use
  • Carry out zero point correction for the controller and adapt the actuator.
  • The differential pressure settings can be adjusted at a later stage using an adjustment device

VRP-M

Constant pressure control

The differential pressure setpoint value as given in the order code is stored as Δpmin in the controller. The nominal differential pressure Δpnom is the reference unit.

To maximise the control accuracy, different pressure ranges with the corresponding nominal differential pressures are used. The correct range is factory set. It is possible to change Δpmin at a later stage but only within the factory set pressure range.

Variable pressure control

A setpoint value signal enables variable pressure control. The control range is Δpmin to Δpmax, based on the setpoint value signal 0 (2) – 10 V.

Volume flow and differential pressure controller VRP-M

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Supply voltage (DC)

24 V DC ± 10 %

Power rating (AC)

including differential pressure transducer, without actuator max. 2.6 VA

Power rating (DC)

including differential pressure transducer, without actuator max. 1.1 VA

Setpoint value signal input

0 – 10 V DC, Ra > 200 kΩ

Actual value signal output

0 – 10 V DC, 0.5 mA max.

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Static differential pressure transducer VFP-100

Supply voltage

from the controller

Measuring range

0 – 100 Pa

Linearity

± 1 Pa

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Static differential pressure transducer VFP-600

Supply voltage

from the controller

Measuring range

0 – 600 Pa

Linearity

± 6 Pa

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Actuators NM24A-V and NM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

3.5 W max.

Torque

10 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.710 kg


Actuators SM24A-V and SM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

4 W max.

Torque

20 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.910 kg


Spring return actuators NF24A-V and NF24A-V-ST

Supply voltage

from the controller

Power rating (AC)

9 VA max.

Power rating (DC)

6.5 W max.

Torque

10 Nm

Running time for 90°

200 – 300 s

Spring return time

< 20 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

1.91 kg


Fast-running actuator LMQ24A-SRV-ST

Supply voltage

from controller VRP-M

Power rating (AC)

23 VA max.

Power rating (DC)

13 W max.

Torque

4 Nm

Running time for 90°

2.5 s

Control signal

from controller VRP-M

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.810 kg


Fast-running actuator NMQ24A-SRV-ST

Supply voltage

from controller VRP-M

Power rating (AC)

23 VA max.

Power rating (DC)

13 W max.

Torque

8 Nm

Running time for 90°

4 s

Control signal

from controller VRP-M

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.970 kg


VRP-M, Pressure ranges

Differential pressure transducer ∆plimit Min Max ∆pnom
Differential pressure transducer ∆plimit ∆pnom
Room



VFP 100

2.5

30

80

100

VFP 100

2.5

15

40

50

VFP 100

2.5

7.5

20

25






Duct



VFP 600

15

180

480

600

VFP 600

7.5

90

240

300

① Min: Minimum value for ∆pmin and ∆pmax

② Max: Maximum value for ∆pmin and ∆pmax

Using a control signal also setpoint values < 30 % of Δpnom can be set. Pressure values smaller than Δplimit will be set to zero because they cannot be precisely controlled.


Application

  • Electronic differential pressure controller VRP-STP, combined with a static differential pressure transducer VFP-100 or VFP-600, as Universal controller
  • Variable or constant differential pressure control
  • The differential pressure is measured using the static measurement principle
  • Voltage range for the actual and setpoint value signals 2 – 10 V DC
  • Separate inputs for override controls enable the centralised switching of groups of controllers

Construction

Differential pressure controller VRP-STP with static differential pressure transducer VFP-100

  • BG3: Actuator NM24A-V for TVR, TVJ, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK
  • BG1: Actuator SM24A-V-ST for TVT
  • BGB: Spring return actuator NF24A-V for TVR, TVJ, TVT, TZ-Silenzio, TA-Silenzio, TVZ, TVA, TVRK


Differential pressure controller VRP-STP with static differential pressure transducer VFP-600

  • BH3: Actuator NM24A-V for TVR, TVJ, TVRK
  • BH1: Actuator SM24A-V-ST for TVT
  • BHB: Spring return actuator NF24A-V for TVR, TVJ, TVT, TVRK

Signal voltage ranges

  • 2: 2 – 10 V DC

Operating modes

  • Z: Supply air
  • A: Extract air

Factory settings are as follows: Differential pressure ∆pmin as ordered and for room pressure controllers the adequate ∆pnom. The effective pressure sensor of the VAV terminal unit is short circuited.

Commissioning

  • On-site adjusting is not required
  • When installing the VAV terminal units it is important to assign each room the correct unit based on the ordered differential pressures
  • Tubing of the static differential pressure transducer by others
  • For positive room pressure: Connect room pressure to Plus, reference room to Minus
  • For negative room pressure: Connect room pressure to Minus, reference room to Plus
  • For supply air duct pressure: Connect static pressure of the duct to Plus
  • For extract air duct pressure: Connect static pressure of the duct to Minus
  • After successful installation, tubing and wiring the controller is ready for use
  • Carry out zero point correction for the controller and adapt the actuator.
  • The differential pressure settings can be adjusted at a later stage using a potentiometer

VRP-STP

Constant pressure control

The differential pressure setpoint value that has been ordered (order code) is factory set as Δp in the controller. The nominal differential pressure Δpnom is the reference unit.

To maximise the control accuracy, different pressure ranges with the corresponding nominal differential pressures are used. The correct range is factory set. It is possible to change Δp at a later stage but only within the factory set pressure range.

Variable pressure control

A setpoint value signal enables variable pressure control. The control range is from Δplimit to Δpmax.

Differential pressure controller VRP-STP

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Power rating (AC)

including static differential pressure transducer, without actuator max. 2.6 VA

Setpoint value signal input

2 – 10 V DC, Ra >100 kΩ

Actual value signal output

2 – 10 V DC linear, max. 0.5 mA

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Static differential pressure transducer VFP-100

Supply voltage

from the controller

Measuring range

0 – 100 Pa

Linearity

± 1 Pa

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Static differential pressure transducer VFP-600

Supply voltage

from the controller

Measuring range

0 – 600 Pa

Linearity

± 6 Pa

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Actuators NM24A-V and NM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

3.5 W max.

Torque

10 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.710 kg


Actuators SM24A-V and SM24A-V-ST

Supply voltage

from the controller

Power rating (AC)

6 VA max.

Power rating (DC)

4 W max.

Torque

20 Nm

Running time for 90°

150 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

0.910 kg


Spring return actuators NF24A-V and NF24A-V-ST

Supply voltage

from the controller

Power rating (AC)

9 VA max.

Power rating (DC)

6.5 W max.

Torque

10 Nm

Running time for 90°

200 – 300 s

Spring return time

< 20 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54

EC conformity

EMC according to 2014/30/EU

Weight

1.91 kg


VRP-STP, Pressure ranges

Differential pressure transducer Δplimit Min Max ∆pnom
Differential pressure transducer Δplimit ∆pnom
Room



VFP 100

2.5

30

80

100

VFP 100

2.5

15

40

50

VFP 100

2.5

7.5

20

25






Duct



VFP 600

15

180

480

600

VFP 600

7.5

90

240

300

① Min: Minimum value (10 V) for ∆p

② Max: Maximum value (10 V) for ∆p

Using a control signal also setpoint values < 30 % of Δpnom can be set. Pressure values smaller than Δplimit will be set to zero because they cannot be precisely controlled.

Variable pressure control requires that the link between terminals 2 and 4 is removed.


Application

  • Electronic volume flow controller GUAC-S3 with integral static differential pressure transducer
  • Variable or constant differential pressure control
  • The differential pressure is measured using the static measurement principle
  • Voltage range for the actual and setpoint value signals 0 – 10 V DC or 2 – 10 V DC

Construction

Volume flow controller GUAC-P1

  • XE1: Actuator 227-024-08-V for TVR, TVJ, TVT, TVRK
  • XE3: Spring return actuator 361C-024-20-V/ST07 for TVR, TVJ, TVT, TVRK


Volume flow controller GUAC-P6

  • XF1: Actuator 227-024-08-V for TVR, TVJ, TVT, TVRK
  • XF3: Spring return actuator 361C-024-20-V/ST07 for TVR, TVJ, TVT, TVRK

Signal voltage ranges

  • 0: 0 – 10 V DC
  • 2: 2 – 10 V DC with shut-off function (< 0.8 V DC)

Operating modes

  • Z: Supply air
  • A: Extract air

The required differential pressure is set at the factory. The effective pressure sensor of the VAV terminal unit is short circuited.

Commissioning

  • On-site adjusting is not required
  • When installing the VAV terminal units it is important to assign each room the correct unit based on the ordered differential pressures
  • Tubing of the static differential pressure transducer by others
  • For positive room pressure: Connect room pressure to Plus, reference room to Minus
  • For negative room pressure: Connect room pressure to Minus, reference room to Plus
  • For supply air duct pressure: Connect static pressure of the duct to Plus
  • For extract air duct pressure: Connect static pressure of the duct to Minus
  • After successful installation, tubing and wiring the controller is ready for use
  • Carry out zero point correction for the controller using adjustment device AT-VAV-G
  • The differential pressure settings can be adjusted at a later stage using an adjustment device

GUAC-P1, GUAC-P6

Constant pressure control

The differential pressure setpoint value as given in the order code is stored as Δpmin in the controller. The nominal differential pressure Δpnom is the reference unit.

To maximise the control accuracy, different pressure ranges with the corresponding nominal differential pressures are used. The correct range is factory set. It is possible to change Δpmin at a later stage but only within the factory set pressure range.

Variable pressure control

A setpoint value signal enables variable pressure control. The control range is Δpmin to Δpmax, based on the setpoint value signal 0 (2) – 10 V.

Differential pressure controller GUAC-P1

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Supply voltage (DC)

24 V DC ± 20 %

Power rating (AC)

without actuator max. 1.2 VA

Power rating (DC)

without actuator max. 0.6 W

Measuring range

0 – 100 Pa

Linearity

± 1 Pa

Setpoint value signal input

0 – 10 V DC, Ra > 100 kΩ

Actual value signal output

0 – 10 V DC, 0.5 mA max.

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Differential pressure controller GUAC-P6

Supply voltage (AC)

24 V AC ± 20 %, 50/60 Hz

Supply voltage (DC)

24 V DC ± 20 %

Power rating (AC)

without actuator max. 1.2 VA

Power rating (DC)

without actuator max. 0.6 W

Measuring range

0 – 600 Pa

Linearity

± 6 Pa

Setpoint value signal input

0 – 10 V DC, Ra > 100 kΩ

Actual value signal output

0 – 10 V DC, 0.5 mA max.

IEC protection class

III (protective extra-low voltage)

Protection level

IP 42

EC conformity

EMC according to 2014/30/EU


Actuator 227-024-08-V

Supply voltage

from the controller

Power rating (AC)

3 VA max.

Power rating (DC)

2 W max.

Torque

8 Nm

Running time for 90°

60 – 120 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54 (cable entry at the bottom)

EC conformity

EMC according to 2014/30/EU

Weight

0.530 kg


Spring return actuator 361C-024-20-V

Supply voltage

from the controller

Power rating (AC)

10 VA max.

Power rating (DC)

8 W max.

Torque

20 Nm

Running time for 90°

150 s

Spring return time

< 15 s

Control signal

from the controller

IEC protection class

III (protective extra-low voltage)

Protection level

IP 54 (cable entry at the bottom)

EC conformity

EMC according to 2014/30/EU

Weight

1.8 kg


Downloads

product information

operation manuals

production {"X-Frame-Options"=>"SAMEORIGIN", "X-XSS-Protection"=>"1; mode=block", "X-Content-Type-Options"=>"nosniff", "X-Download-Options"=>"noopen", "X-Permitted-Cross-Domain-Policies"=>"none", "Referrer-Policy"=>"strict-origin-when-cross-origin", "Strict-Transport-Security"=>"max-age=31536000; includeSubDomains", "Content-Type"=>"text/html; charset=utf-8"}

Share page

Recommend this page

Recommend this page by sending a link by mail.

Fields marked with an (*) are required fields.

Share page

Thank you for your recommendation!

Your recommendation has been sent and should arrive shortly.

Contact

We are here for you

Please specify your message and type of request.
Tel.: +60 6 678 8188 | Fax: +60 6 678 8288 (388)

Attachment (max. 10MB)

Fields marked with an (*) are required fields.

Contact

Thank you for your message!

Your message is send and will be processed shortly.
Our department for Service-Requests will contact you asap.
For general question regarding products or services you can also call:
Tel.: +60 6 678 8188 | Fax: +60 6 678 8288 (388)

Contact

We are here for you

Please specify your message and type of request.
Tel.: +60 6 678 8188 | Fax: +60 6 678 8288 (388)

Attachment (max. 10MB)

Fields marked with an (*) are required fields.

Contact

Thank you for your message!

Your message is send and will be processed shortly.
Our department for Service-Requests will contact you asap.
For general question regarding products or services you can also call:
Tel.: +60 6 678 8188 | Fax: +60 6 678 8288 (388)
